DMX USB Pro

The DMX USB Pro is the industry standard DMX USB converter for DMX/RDM. Control your lights from PC or MacOS software.

SKU: 70304

The industry standard USB to DMX converter.

Products don’t become an industry standard for no reason. Used on a daily basis by countless lighting designers and installers across the world, the DMX USB PRO converter has proven for many years that it’s a reliable and robust product that excels at so many fundamental applications.

Designed for simple USB connections across Windows, Mac and Linux, this device is compatible with an enormous range of commercial and free software.

The DMX USB converter supports either DMX Input or DMX Output mode and comes RDM-enabled and has an internal frame buffer for steady DMX generation.

With industry standard-5 pin input and output connections as well as 1500V full isolation for both data and power lines, you can rest assured that your computer will be protected.

Features an internal frame buffer for consistent DMX generation, therefore isn’t dependent on your computer’s processor to regulate a steady, reliable flow of data.

Industry Standard USB 2.0 support on Windows PC and MacOS, and popular Linux flavours. Even Raspberry Pi is supported, for the hobbyist within you!

Refresh rate is fully configurable from 1 to 40 fps. Break time is configurable from 96uS to 1.3mS, and MaB is configurable from 10.6uS to 1.3mS. You can even change the firmware to support your requirement.

Let’s get started!

It’s so easy to produce great shows and ambiences with a DMX USB PRO as part of your lighting kit.

Follow this short demonstration to learn about the essential features of the device, and see how simple it is to set up.

You’ll be thrilling your audiences in no time!

Bonus
software!

3-month PREMIUM EMU license when you purchase a new DMX USB PRO.

Specifications

Input voltage5V DC (via USB)
Input current 300mA
Power draw 1.5W
Connectors 1 x DMX output (female XLR5), 1 x DMX input (male XLR5), 1 x USB 2.0 Type-B
ProtocolsUSITT DMX512-A, ANSI E1.20 RDM1
Maximum output channels1 universe (512ch)
Max. output refresh rate40FPS
Configuration softwareENTTEC EMU
Firmware updatesENTTEC EMU
LED status indicatorYes
Standalone playbackNo
MIDINo
Body materialABS plastic
IP ratingIP20
Operating temperature0°-50°C / 32°-122°F
Operating humidity5- 95% (non-condensing)
Mounting optionsN/A
Unit dimensions80mm (3.12in) x 58mm (2.28in) x 40mm (1.57in)
Unit weight80 g / 0.18lbs
Shipping dimensions237mm x 165mm x 71mm
Shipping weight0.30kg / 0.66lbs
Warranty3-year return to base manufacturer warranty
ComplianceRCM (Aus/NZ), CE / WEEE (EU), UKCA (UK), FCC (USA)

Resources

DMX USB PRO data sheet

DMX USB PRO user manual

Firmware v1.44 (DMX only)

Firmware v2.4 (RDM+DMX)

Windows D2XX Drivers

Driver for WYSIWYG

API for DMX USB PRO

C/C++Example

Net5Example

Knowledge base
